Steel Strand 1x7 DIN3052 Galvanized Carbon Steel Wire Rope/cable
Steel Strand 1x7 DIN3052 Galvanized Carbon Steel Wire Rope/cable
Specification |
Normal Diameter | Approx Weight | Nominal Tensile Strength | |
Minimum Breaking Strength (kN) | |||
mm | kg/100m | 1570N/mm2 | 1770N/mm2 |
0.6 | 0.18 | 0.308 | 0.347 |
0.8 | 0.32 | 0.547 | 0.617 |
1 | 0.5 | 0.855 | 0.963 |
1.5 | 1.13 | 1.92 | 2.17 |
2 | 2.01 | 3.42 | 3.85 |
2.5 | 3.14 | 5.34 | 6.02 |
3 | 4.52 | 7.69 | 6.67 |
3.5 | 6.15 | 10.5 | 11.8 |
4 | 8.03 | 13.7 | 19.5 |
4.5 | 10.2 | 17.3 | 19.5 |
5 | 12.6 | 21.4 | 24.9 |
6 | 18.1 | 30.8 | 34.4 |
7 | 24.6 | 41.9 | 47.34 |
8 | 32.1 | 54.7 | 60.5 |
Production process |
Installation of steel wire rope |
Unwinding: when unwinding, the wire rope shall be coiled around an iron tube which is mounted on a special-purpose support. Keeping parallel with the ground. Then turn the wheel to unwind the rope.
Arrangement of steel wire rope on the reel: the winding direction of the wire rope on the reel must be in accordance with the rope's twisting direction, from left to right for right-twisted rope, from right to left for left-twisted rope. The arrangement shaa be in good order and neat, avoiding from winding deviation or sandwiched winding.
Feature |
Cheaper than stainless steel wire rope
Higher break strength than stainless steel
Greater fatigue strength
Excellentcorrision resistant
Less wear than other materials
Galvanized coating serves as lubricant to reduce friction
Remain ductile over long periods of working
Easier to inspect for corrosion damage
